CTSCK |
 |
 |
| ˇiSwivelˇj |
|
|
|
| Tube(
m / m ) - Thread( PT ) |
| Style |
 D |
R |
F |
P |
L1 |
L2 |
H |
d |
| CTSCK04M5 |
4 |
M5x0.8 |
10 |
12 |
20.6 |
18.6 |
36.7 |
4.3 |
| CTSCK0401 |
1/8 |
| CTSCK0402 |
1/4 |
14 |
| CTSCK06M5 |
6 |
M5x0.8 |
12 |
14 |
22.4 |
20.4 |
40.1 |
| CTSCK0601 |
1/8 |
| CTSCK0602 |
1/4 |
14 |
| CTSCK0603 |
3/8 |
17 |
| CTSCK0801 |
8 |
1/8 |
14 |
16 |
24.1 |
21.9 |
48.5 |
| CTSCK0802 |
1/4 |
| CTSCK0803 |
3/8 |
17 |
| CTSCK1002 |
10 |
1/4 |
21 |
29.1 |
26.8 |
50.8 |
| CTSCK1003 |
3/8 |
| CTSCK1004 |
1/2 |
21 |
| CTSCK1202 |
12 |
1/4 |
19 |
51.8 |
| CTSCK1203 |
3/8 |
| CTSCK1204 |
1/2 |
21 |
|
| |
| Tube(
Inch ) - Thread( NPT ) |
| Style |
D |
R |
F |
P |
L1 |
L2 |
H |
d |
| CTSCK041032 |
5/32 |
10-32UNF |
10 |
12 |
20.6 |
18.6 |
36.7 |
4.3 |
| CTSCK0401N |
1/8 |
| CTSCK0402N |
1/4 |
14 |
| CTSCK071032 |
1/4 |
10-32UNF |
12 |
14 |
22.4 |
20.4 |
40.1 |
| CTSCK0701N |
1/8 |
| CTSCK0702N |
1/4 |
14 |
| CTSCK0703N |
3/8 |
17 |
| CTSCK0801N |
5/16 |
1/8 |
14 |
16 |
24.1 |
21.9 |
48.5 |
| CTSCK0802N |
1/4 |
| CTSCK0803N |
3/8 |
17 |
| CTSCK0902N |
3/8 |
1/4 |
21 |
29.1 |
26.8 |
50.8 |
| CTSCK0903N |
3/8 |
| CTSCK0904N |
1/2 |
21 |
| CTSCK1302N |
1/2 |
1/4 |
19 |
51.8 |
| CTSCK1303N |
3/8 |
| CTSCK1304N |
1/2 |
21 |
|
| |
| Tube(
m / m ) - Thread(G) |
| Style |
D |
R |
F |
P |
L1 |
L2 |
H |
d |
| CTSCK04M5 |
4 |
M5x0.8 |
10 |
12 |
21.6 |
18.6 |
36.7 |
4.3 |
| CTSCK0401G |
1/8 |
| CTSCK0402G |
1/4 |
14 |
| CTSCK06M5 |
6 |
M5x0.8 |
12 |
14 |
23.4 |
20.4 |
40.1 |
| CTSCK0601G |
1/8 |
| CTSCK0602G |
1/4 |
14 |
| CTSCK0603G |
3/8 |
17 |
| CTSCK0801G |
8 |
1/8 |
14 |
16 |
25.1 |
21.9 |
48.5 |
| CTSCK0802G |
1/4 |
| CTSCK0803G |
3/8 |
17 |
| CTSCK1002G |
10 |
1/4 |
21 |
30.1 |
26.8 |
50.8 |
| CTSCK1003G |
3/8 |
| CTSCK1004G |
1/2 |
21 |
| CTSCK1202G |
12 |
1/4 |
19 |
51.8 |
| CTSCK1203G |
3/8 |
| CTSCK1204G |
1/2 |
21 |
|
